Picked up this Original Paint 69 recently

[sixt9rsx33]

Originally Posted by Postsedan

She`s a Beauty Lawrence

She`s in great hands!

What`s causing that hood to sit like that?

Dan

Thanks Dan.

That is a great question, I have not looked into it. Will check it out. I have a lot of extra time on my hands now, ha ha. Maybe just St Louis quality of 1969!

[Tracker1]

Originally Posted by sixt9rsx33

Thanks Dan.

That is a great question, I have not looked into it. Will check it out. I have a lot of extra time on my hands now, ha ha. Maybe just St Louis quality of 1969!

I believe the dimples in the fiberglass around the headlight doors tell the tale. The heavy nose droops over time but the hood stays where it is because of the front mounted hinges. It's a C3 thing.

[Lynn]

Originally Posted by Tracker1

I believe the dimples in the fiberglass around the headlight doors tell the tale. The heavy nose droops over time but the hood stays where it is because of the front mounted hinges. It's a C3 thing.

Actually the dimples are a result of the aluminum rivets on the header bar corroding and expanding. I have the same issue on my 70 LT-1.

Apparently, if you are very careful, you can do a repair without painting, but it is a PITA.

Plan to attack mine when I have the body off the frame.

[firstgenaddict]

Originally Posted by Lynn

Actually the dimples are a result of the aluminum rivets on the header bar corroding and expanding. I have the same issue on my 70 LT-1.

Apparently, if you are very careful, you can do a repair without painting, but it is a PITA.

Plan to attack mine when I have the body off the frame.

I have discussed it at length with people who have done it...
They say to do it without removing the body from the frame and with mindset of saving original paint - is about a 100-150 hour job.
The entire headlamps assemblies must be removed and removing the radiator and radiator support allow a heck of a lot more room.
Doing it with the car inverted or at least rotated on it's side would surely cut off a significant number of hours.

[Big Block 69]

I had the bumps on my 69 "repaired" 40 years ago. I wish now that I hadn't. Now the repairs are starting to show. The bumps looked better. I have also seen on other boards where people feel better buying a car with the bumps. They know at least that part of the car has not been molested. There was a post on another board outlining the procedure to address the bumps without disturbing the paint. As stated, it is very labor intensive, but the people who did it were glad they chose that method.

Originally Posted by firstgenaddict

I have discussed it at length with people who have done it...
They say to do it without removing the body from the frame and with mindset of saving original paint - is about a 100-150 hour job.
The entire headlamps assemblies must be removed and removing the radiator and radiator support allow a heck of a lot more room.
Doing it with the car inverted or at least rotated on it's side would surely cut off a significant number of hours.

[Lynn]

Originally Posted by firstgenaddict

I have discussed it at length with people who have done it...
They say to do it without removing the body from the frame and with mindset of saving original paint - is about a 100-150 hour job.
The entire headlamps assemblies must be removed and removing the radiator and radiator support allow a heck of a lot more room.
Doing it with the car inverted or at least rotated on it's side would surely cut off a significant number of hours.

My investigation revealed the same. I am replacing a rusty frame anyway, so figured it would be best to do it with the body off the frame.
