Re: 70 Nova TCS Relay
Dennis,
In all the photos I sent you there were some close up detail shots of the TCS routing. Did you copy any of them? Rick
__________________
Rick Nelson Musclecar Restoration and Design, Inc (retired) www.musclecarrestorationanddesign.com https://www.youtube.com/watch?v=62r-6vgk2_8 specialized in (only real) LS6 Chevelle restorations
|
|
#33
01-20-2003, 08:22 PM
|
|||
|
|||
|
Re: 70 Nova TCS Relay
Rick,Rick,
Most of it is clear but the tee and a couple of the lines are obscured by the PCV hose. I'm just wondering which lines come off the two nipples on the side of the tee. I would guess one end goes to the carb base and the other to the TCS. Then I'm guessing the side nipple farthest from the carb is the AIR and the closest is the choke diaphragm. I picked up two different metal lines from Repro vendors but neither were 100% accurate so I ended up making my own based on photos from a number of other cars. I also have a metal section in the line from the TCS to Distributor. Again, one of those things I should have recorded in Chicago!
